Version 2.2 Page 33 of 39 SMT6035 User Manual
15.6.19 RecallHandlers
During the normal procedure for closing a handler, the DSP sends a
HSC_CloseHandler control word to the host.
In some cases, the host-side software needs to unload the handler, and
to break the connection between the DSP and the handler.
Calling RecallHandlers() will signal any running handlers to terminate. It
will also put the host into a state where it will absorb all the control
words received from the DSP without doing anything with them. The
DSP will no longer be able to communicate with any handlers. This
state will last until the DSP is reset, in which case the default handler
will be reselected.
Prototype
void IFHw::RecallHandlers( void )
Parameters
None
16 Board state
You usually need to reset the TIMs on the carrier board before downloading your
application.
16.1 ResetTIMs
Resets the TIMs on the carrier board.
Prototype
void IFHw::ResetTIMs(void)
16.2 ResetBoard
Resets the carrier board. This function resets the TIMs and the JTAG controller.
Prototype
void IFHw::ResetBoard(void)
17 Read and write carrier board registers
The SMT6035 gives you access to the carrier board registers. Thus, you can
perform any low level accesses that you might require.
Please refer to the carrier board User Manual for a description of the carrier
board registers and BAR address mapping.
The register access is specified by a BAR address and offset values.
User Manual - Version 2.2, 04/01/07; © Sundance Italia S.R.L.
