Version 2.2 Page 36 of 39 SMT6035 User Manual
18.4 PciWrite8
Writes 8 bits to the PCI register specified.
Prototype
void IFHw::PciWrite8( DWORD dwReg, BYTE cValue )
18.5 PciVirtualAddr
Returns the virtual memory address for the Base Address Region specified.
Prototype
void IFHw::PciVirtualAddr( UINT nBar, void *&pVirtAddr )
19 DSP interrupt
The DSP (C40) interrupt is a mechanism that was inherited from a previous
generation of carrier boards and is still supported in the current generation.
The DSP interrupt allows the DSP to interrupt the host.
The DSP can generate a DSP interrupt to the host by toggling the IIOF1 line.
With SMT6035, you can attach an interrupt function to this event. Unlike
mailboxes, no data is transferred with this type of interrupt.
Please refer to the examples for the DSPInt interrupt example.
19.1 DspAttatchInt
Attaches a user-specified function that is to be called when a DSP interrupt
occurs.
Prototype
void IFHw::DspAttatchInt( PFN_DSP_INT pDSPIntFunc )
Parameters
pDSPIntFunc Pointer to the function that is to be called when the DSP
interrupt occurs.
20 Memory allocation
You can make minor improvements in the performance of the HSC by using
contiguous memory. The following functions make possible to allocate such
memory.
