Specifications
Interface
HD Video Formats SMPTE 292M-1998
SD Video Formats SMPTE 259M-1997
Nominal Amplitude 800mV peak-to-peak terminated
Autophasing range TBD
Channel Coding conforms to SMPTE 259M, SMPTE 292M
Ancillary Data Blanked or passed (user selectable)
Embedded audio Blanked or passed (user selectable)
EDH Blanked
Input Impedance 75 ohm
Max cable length
HD Video 100 meters using Belden 1694A type cable
SD Video 300 meters using Belden 1694A type cable
Table 7. Serial Digital Video Outputs
Format
ITU-R656, SMPTE 259M, 270Mbit/s.
SMPTE 292M, 1.5Gbit/s
Number of Outputs
Frame w/ 1 ME Board: 12
Frame w/ 2 ME Boards: 24
Frame w/ 3 ME Boards: 36
Frame w/ 4 ME Boards: 48
Return loss > 15 db, 5 MHz to 1.5 GHz
Type of Connector 75 ohm BNC (SMPTE 259M)
Interface
HD Video Formats SMPTE 292M-1998
SD Video Formats SMPTE 259M-1997
Nominal Amplitude 800 mv peak-to-peak across 75 ohm
Rise & Fall Times
400 to 1400picoseconds 75 ohm termination
between 20% and 80% amplitude
Jitter ITU R 601/656
Output Impedance 75 ohm
DC Offset < 50mV with 75 ohm termination
Table 8. Analog Reference Input
Video Standard
For HD Video: Tri-level Sync, Analog equivalent to the standard being used
For SD Video: Color Black, Analog equivalent to the standard being used
Return loss > 40dB, up to 5 MHz
Connectors 2 each BNC loop through for both HD and SD inputs
Impedance 75 ohm external
Table 6. Serial Digital Video Inputs
