150
SPECIFICATIONS
600 RUSH PRO-S
Capacities and Dimensions
Body Style AXYS
Rider Capacity 1
Coolant Capacity 4 qts. (3.8 l)
Chaincase Oil Capacity Fill to Spill / 8 - 10 oz. (237 - 296 ml)
Dependent on sprocket / chain size
Fuel Tank Capacity 12 gal. (45.4 l)
Height 46 inches (117 cm)
Length 114 inches (289.6 cm)
Estimated Dry Weight 432 lbs. (196 kg)
Oil Capacity 3.8 qts. (112.4 l)
Designed Width
Ski Center Distance 47 inches (119.4 cm)
42.5 inches (108 cm)
Brake Type
Fluid Hayes Phantom Floating Piston
DOT 4
Drive Clutch Center Distance 10.625 inches (26.97 cm)
Drive Belt Type
Projected Width PBO- Double Cog, Cut Finish
1.46 inches (3.7 cm)
Drive / Driven Clutches P-85 / Team LWT
Reverse POLARIS Electronic Reverse Control (PERC)
Front / Rear Travel 9.3 in. (23.6 cm) / 13.6 in. (34.5 cm)
Engine and Cooling
Engine S5120-6044-OS6P
Displacement 599cc
Cylinders 2
Bore x Stroke (mm) 77.25 x 64
Alternator Output 400 watt
Throttle Body Mikuni
Oil Injection Electronic Oil Pump
Throttle Body Bore Size 46 mm
Idle RPM 1700 +/- 200
Operating RPM 8250 +/- 200
Cooling
Thermostat Opening Temp Liquid
120°F (49°C)
Ignition Type Multi-Dimensional CDI
Ignition Timing 18° @ idle 1700 RPM w/120°F (49°C) water temp
Spark Plug / Gap NGK BPR9ES /.027 inches (0.7 mm)
Recommended Fuel Octane 91 non-oxygenated recommended
(87 oxygenated minimum)
