HEIDENHAIN TNC 640 157
5.8 Pr
ogr
amming Examples
5 CYCL DEF 256 RECTANGULAR STUD Define cycle for machining the contour outside
Q218=90 ;1ST SIDE LENGTH
Q424=100 ;WORKPC. BLANK SIDE 1
Q219=80 ;2ND SIDE LENGTH
Q425=100 ;WORKPC. BLANK SIDE 2
Q220=0 ;CORNER RADIUS
Q368=0 ;ALLOWANCE FOR SIDE
Q224=0 ;ANGLE OF ROTATION
Q367=0 ;STUD POSITION
Q207=250 ;FEED RATE FOR MILLING
Q351=+1 ;CLIMB OR UP-CUT
Q201=-30 ;DEPTH
Q202=5 ;PLUNGING DEPTH
Q206=250 ;FEED RATE FOR PLNGNG
Q200=2 ;SET-UP CLEARANCE
Q203=+0 ;SURFACE COORDINATE
Q204=20 ;2ND SET-UP CLEARANCE
Q370=1 ;TOOL PATH OVERLAP
6 L X+50 Y+50 R0 M3 M99 Call cycle for machining the contour outside
7 CYCL DEF 252 CIRCULAR POCKET Define CIRCULAR POCKET MILLING cycle
Q215=0 ;MACHINING OPERATION
Q223=50 ;CIRCLE DIAMETER
Q368=0.2 ;ALLOWANCE FOR SIDE
Q207=500 ;FEED RATE FOR MILLING
Q351=+1 ;CLIMB OR UP-CUT
Q201=-30 ;DEPTH
Q202=5 ;PLUNGING DEPTH
Q369=0.1 ;ALLOWANCE FOR FLOOR
Q206=150 ;FEED RATE FOR PLNGNG
Q338=5 ;INFEED FOR FINISHING
Q200=2 ;SET-UP CLEARANCE
Q203=+0 ;SURFACE COORDINATE
Q204=50 ;2ND SET-UP CLEARANCE
Q370=1 ;TOOL PATH OVERLAP
Q366=1 ;PLUNGE
Q385=750 ;FEED RATE FOR FINISHING
8 L X+50 Y+50 R0 FMAX M99 Call CIRCULAR POCKET MILLING cycle
9 L Z+250 R0 FMAX M6 Tool change
