HEIDENHAIN TNC 640
239
8.7 A
d
ditional F
unctions
Pocket table data, 51
1
Pocket number
Tool number
2
Pocket number
Special tool: 0=no, 1=yes
3
Pocket number
Fixed pocket: 0=no, 1=yes
4
Pocket number
Locked pocket: 0=no, 1=yes
5
Pocket number
PLC status
Pocket number of a tool in the
tool-pocket table, 52
1
Tool no.
Pocket number
2
Tool no.
Tool magazine number
Values programmed immediately
after TOOL CALL, 60
1
-
Tool number T
2
-
Active tool axis
0 = X 6 = U
1 = Y 7 = V
2 = Z 8 = W
3
-
Spindle speed S
4
-
Tool length oversize DL
5
-
Tool radius oversize DR
6
-
Automatic TOOL CALL
0 = yes, 1 = no
7
-
Tool radius oversize DR2
8
-
Tool index
9
-
Active feed rate
Values programmed immediately
after TOOL DEF, 61
1
-
Tool number T
2
-
Length
3
-
Radius
4
-
Index
5
-
Tool data programmed in TOOL DEF
1 = yes, 0 = no
Group name, ID no.
Number
Index
Meaning
