Bi-Color LED
Status Indicator
(Red/Green)
Bi-Color LEDs
Link Activity
Ethernet
RJ11 Jack
To Inverter
RJ11 Jack
To Remote
SN: MW50000 PN: ME-MW-E
Back View
Top View
Front View
© 2011 Magnum Energy, Inc. 9
Figure 4-1, MagWeb Wired Ethernet LED Diagram
4.0 Using LED Indicators to Determine Magweb’s Status
