FIG.5
17. Make sure the Outer Leg Caps (P1) and Inner Leg Caps (P2) are installed into the ends of the leg. Then place the
Wheel (#18) into the Legs. See FIG. 5.
18. With the logo upside-down, attach the Plastic Panel with Frame (#21) to the Curved Inner Leg (#6) using
two Bolts (#A3) and two Washers (#A4) per frame.
NOTE: Do not tighten securely at this time.
9
X 4
X 4
X 1
X 2
X 4
A4
A3
A9
21
18
Player
A4
6
5
A4
A3
A3
A9
21
21
18
18
FIG. 5
P1
P2
