3. Place Table Surface-A (#1) and Table Surface-B (#2) with the painted surface facing down on a flat surface.
4. Connect Table Surfaces together using three Brackets (#9) using twelve Screws (#A7). See FIG. 1 and 1A.
5. Attach the Safety Strap - Long (#13) and Safety Strap - Short (#14) to the surface using three Screws (#A1).
See FIG. 1.
1
1
9
9
2
2
13
14
14
A7
A1
A1
Note:
Align the inside seams of
each sections so that
pre-drilled holes line up
across from each other.
Note: Center gap tolerance
approximately 10~13mm.
Player
Player
Center
FIG. 1
FIG. 1A
1
X 2
X 2
X 6
9
2
X 1
X 2
13
14
X 3
A1
X 24
A7
