Page 8
7
FIG.3
9. Attach one end of the Linkage Tube (#8) to the inside of the Curved Outer Leg (#5) using one Bolt (#A2), two
Washers (#A4), one Spacer (#A5) and one Nut (#A6). See FIG. 3A.
10. Repeat the same for the other end of this Linkage Tube, only attaching it to the outside of the Curved
Inner Leg (#6).
11. Attach one end of the Linkage Tube with Stop Bracket (#7) to the inside of the Curved Outer Leg (#5) using
one Bolt (#A2), two Washers (#A4), one Spacer (#A5) and one Nut (#A6).
12. Repeat the same for the other end of this Linkage Tube, only attaching it to the outside of the Curved
Inner Leg (#6). See FIG 3B.
13. Repeat the above steps for the other table half.
X 8
X 2
X 2
7
8
A8
X 1
A6
X 1
A9
A2
X 16
X 8
A4
X 8
A5
Player
Player
Center
FIG. 3A
FIG. 3
7
8
A8
A9
5
6
FIG. 3B
A2
7
A6
A5
A4
A4
6
A2
8
A6
A5
A4
5
A4
Note: Be careful of the assembly
direction on pictures when you
assemble the Linkage Tube #7 and
#8 in order to fit the folding function.
