FIG.2
6. Place one Curved Outer Leg with Cap (#5) on the player end of the table half and one Curved Inner Leg with Cap
(#6) on the center end of the table half.
7. Attach the Leg Bracket (#19 & #20) to the Curved Outer Leg (#5) and the Curved Inner Leg (#6) using Screws
(#A7). See FIG. 2A.
8. Repeat the above steps for the other table half.
6
5
6
X 2
X 2
Player
Player
Center
NOTE: Make sure that the
oval cut-out in the Leg
Bracket are facing the
center of the table for
proper installation.
A7
19
19
A7
19
19
6
A7
5
P2
P1
FIG. 2
FIG. 2A
A7
X 64
19
X 8
20
X 4
20
19
20
This is hole for “Gravity
Lock” assembly.
