FIG.4
10. Place one Plastic Corner (#22) flush with table corner,
and attach using three Screws (#A1) per Corner.
See FIG. 4A
11. Place End Apron (#12) between the corners and flush
with the table edge at the Player end of table using
six Screws (#A1) per End Apron.
See FIG. 4.
12. Place Side Apron (#11) flush with table edge at the
side of the table using five Screws (#A1) per Side
Apron.
See FIG. 4.
13. Repeat above steps for other Table Surface.
NOTE: Make sure all Aprons are inside the Plastic
Corners.
FIG.4
10. Coloque una cisterna del Rincón Plástico (#22) con
el rincón de mesa y coloque a través de 3 Tornillos
(#A1) por Rincón.
Vea la FIG. 4A.
11. Coloque el Delantal Final (#12) entre los rincones y
cisterna con el filo de mesa al Jugador final de mesa
usando 6 Tornillos (#A1) por Delantal Final.
Vea la FIG. 4.
12. Coloque la cisterna del Delantal Lateral (#11) con el
filo de mesa del lado de la mesa usando 5 Tornillos
(#A1) por Delantal Lateral.
Vea la FIG. 4.
13. Repita dichos pasos para la otra Superficie de Mesa.
NOTA: Asegúrese que todos los Delantales están
dentro de los Rincones Plástico.
FIG. 4
FIG. 4A
1
2
22
1
1
2
22
1
