62
U
SE
S
OFTWARE
Monitoring and control software
The PowerShield
3
software provides effective and intuitive management of the UPS, displaying all the most
important information, such as input voltage, load applied, and battery capacity.
It is also able to automatically effect operations such as shutdown, transmission of e-mails, SMS and network
messages when particular events that can be selected by the user occur.
Installation procedure:
Connect the UPS’s RS232 communication port to a COM communication port on the PC by means of the
serial cable provided* or connect the USB port on the UPS to a USB port on the PC using a USB standard
cable*.
Download the software from www.riello-ups.com, selecting the desired operating system.
Follow the installation program instructions.
For more detailed information about installation and use, refer to the software manual which can be
downloaded from our website www.riello-ups.com.
Configuration software
Using special software, it is possible to configure the most important UPS parameters.
For a list of possible configurations, refer to the UPS configuration paragraph.
*
You are advised to use a cable of max. length 3 metres.
UPS
PC
RS232
