page 12
Settings, con’t
Touch
Use this parameter to adjust the keyboard touch sensitivity to your playing technique.
Press the Settings button until the screen displays Touch:Linear (factory default). To change the setting, press the
Next+ button to advance to the next desired Touch. Press the Prev- button down to reverse the steps. The following
are the available settings:
Linear Best Dynamic Range for all sounds (Factory Default Setting).
Light (1-3) For players with a light touch. Adjust this parameter to achieve a good dynamic range. These settings
are from Light 1, a slightly light touch, to Light 3, a very light touch.
Hard (1-3) For players with a heavier touch. Adjust this parameter to achieve a good dynamic range. These set-
tings range from Hard 1, a slightly harder touch, to Hard 3, a very hard touch.
Piano Touch Best for piano dynamics.
Easy Touch Light touch, especially for younger players.
GM Receive Select this when playing General MIDI songs.
The Touch setting is remembered across power cycles. Pressing the Prev- / Next+ button pair will reset the Touch
level back to factory default of Linear.
Tune
This parameter allows you to adjust the Andante CUP110 tuning to match other instruments or recordings.
Press the Settings button until the display reads TUNE:0 (factory default is A - 440). To increase the tuning, press
the Next+ button from 0 to 100 cents. To lower or reduce the tuning, press the Prev- button from 0 to -100 cents.
Pressing Prev- / Next+ button pair will reset the tuning back to factory default of 0 or A-440.
MIDI Channel
This parameter controls the MIDI transmit channel used for Voice Mode. Press the Settings button until the display
reads CHANNEL: 1 (Factory Default). You can select Channels 1 through 9, or Channels 11 through 15. Channel 16
is reserved for the metronome. Pressing the Prev- / Next+ button pair will reset the MIDI Channel back to the factory
default of 1.
For more information on MIDI, see the following section of this manual.
Metronome Volume
This setting ranges from 1 (lowest) to 9 (loudest). The default setting is 9. In Settings Mode, press the Prev- or
Next+ button to reach the desired volume level. The Metronome setting is remembered across power cycles.
Local Control
When you play the CUP110 keyboard you hear the resident or “local” voices, because this parameter is normally set to
On. When using your CUP110 with an external sequencer or computer, turn this setting to Off to avoid creating a MIDI
loop which may result in stuck notes or “echoes”. Press either the Prev- or Next+ button to set this parameter.
Auto Power Off
This energy-saving feature will automatically shut off power to the unit after a period of inactivity. Simply pressing
the power button will power up the unit once again. This allows you to reduce overall power consumption, and also
extends the lifetime of the instrument. Press the Settings button until the display reads AutoPowerOff. Options are
