In addition to the visible ports on the sides of the device, certain integrated components
must remain free of obstruction in order to function correctly. These include the
Bluetooth, Wi-Fi, occupancy, and mic sensors as well thermal cooling vents. Keep out
zones
Item
Description
Notes
Access
Ensure unimpeded access to input/output ports, the compute cartridge,
Bluetooth radio, Bluetooth sensor, Wi-Fi radio, Wi-Fi sensor, occupancy sensor.
See
Figure
1.
Air
flow
Avoid blocking inlet and outlet air vent zones.
See
Figure
2
Obstruction free mounting
