Unit testing
Manual Testing
Operate the magnetic test switch by holding the provided magnet near
the status LED, where indicated. This will initiate a one minute test and
the lamps will illuminate. At the end of the test, the unit will automatically
return to stand by mode. Test can be cancelled by holding the magnet
near the test switch again.
Automatic Testing and diagnostics
The automatic testing and diagnostic function includes a micro-
controller which self-tests the unit on a monthly basis and identi-
fies as well displays failures of the electrical components: battery,
battery charger and lamps.
Self-test
The self-test is performed every month for 1 minute, every 6 months
for 30 minutes, and annually for 90 minutes.
Diagnostic function
The diagnostic function uses an external red LED indicator. Service
is required if the red LED is present indicating that an alarm condition
is detected (See fig. 10).
For Nexus models, refer to “Nexus addendum” and for additional infor-
mation about the Nexus system, go to “www.nexus-system.com”.
For more information about the AD function, please consult the web site
for this user manual:
“AD with Single LED Status User Manual”
Food processing facilities
Screw covers are available in the hardware kit. These covers
have to be installed on screws to avoid any food accumulation.
Note: some detergent used in food processing industry can affect
durability of Polycarbonate lens. Install unit on even wall surface
to insure watertightness and avoid any gaps between the gasket
and the wall.
Maintenance (All Models)
None required. If AC supply to the unit is to be disconnected for 2
months or more, the battery must be disconnected.
o Green Steady On AC On
o Red Steady On Battery Disconnect
-o Red Blinking Battery Failure
o-o Red Two Blinks Charger Failure
o-o-o Red Three Blinks Lamp Failure
o
Figure 10
Magnetic test
LED Status
Figure 11
Figure 12
