2
1 Match the guides of the battery pack with the grooves on
the upper rear of the transceiver, then firmly press the
battery pack in place.
2 Lock the safety catch to prevent accidentally releasing the
battery pack.
3 To remove the battery pack, lift the safety catch, press the
release latch, then pull the battery pack away from the
transceiver.
Note:
◆
For battery pack charging procedures and usage, refer to the
battery charger Instruction Manual.
◆ The battery pack is not charged at the factory; charge it before
use.
◆
Install the battery pack after cleaning the battery pack contacts
and the transceiver terminals.
◆ Before charging a battery pack that is attached to the
transceiver, ensure that the safety catch is firmly closed.
PrEPArATION
INSTAllING/ rEMOvING THE (OPTIONAl) BATTEry PACK
Safety catch
Release latch
