4: Connecting the antennas
Connect the supplied AM loop antenna and
FM wire antenna.
* The shape of the connector varies depending on
the area code of this receiver.
Notes
• To prevent noise pickup, keep the AM loop antenna
away from the receiver and other components.
• Be sure to fully extend the FM wire antenna.
• After connecting the FM wire antenna, keep it as
horizontal as possible.
SUB
WOOFER SURROUND
DVD IN
SPEAKERS
AUDIO IN
VIDEO 2
AUDIO IN AUDIO IN
VIDEO 1
AUDIO IN L R
L R
+ +
DIGITAL
L
COAXIAL
AM
ANTENNA
R R
L
L
L
R
OPTICA
SA-CD/CD DVD
VIDEO 2
IN
FM wire antenna (supplied)
AM loop antenna (supplied)
