Page 11 — English
ADDING GASOLINE TO THE FUEL TANK
See Figure 11.
WARNING:
Gasoline and its vapors are highly flammable and
explosive. To prevent serious personal injury and property
damage, handle gasoline with care. Keep away from
ignition sources, handle outdoors only, do not smoke
while adding fuel, and wipe up spills immediately.
When adding gas to the pressure washer, make sure the unit
is sitting on a flat, level surface. If the engine is hot, let the
pressure washer cool before adding gas. ALWAYS fill the
fuel tank outdoors with the machine turned off.
NOTE: This is a 4-cycle engine. DO NOT mix fuel and
lubricant together.

Mix fuel stabilizer with gasoline according to fuel stabilizer
manufacturer’s directions.
 Before removing the fuel cap, clean the area around it.
Remove the fuel cap.
 Insert a clean funnel into the fuel tank then slowly
pour gasoline into the tank. Fill tank to approximately
1-1/2 in. below the top of the tank neck (this allows for
fuel expansion).
 Replace fuel cap and tighten until the cap “clicks”.
 Clean up any spills before starting the engine.
PUMP LUBRICANT
The pressure washer pump has been filled with sufficient
lubricant at the factory. You do not need to check or add
lubricant to the pump.
STARTING AND STOPPING THE PRESSURE
WASHER
See Figures 12 - 13.
NOTICE:
Do not run the pressure washer pump without water
supply connected and turned on, as this may damage the
high pressure seals and decrease pump life. Completely
unwind the hose from its reel or coil and make sure the
hose is not being restricted by tires, rocks, or any other
objects that may lessen or prevent water flow to the
pressure washer.
Before starting the engine:

Connect all hoses.
NOTE: Make sure the pressure washer’s water intake
screen is in place and unclogged before connecting
garden hose.
 Check all fluids (lubricant and gas).
 Turn on the garden hose then pull the trigger to relieve air
pressure; hold the trigger until a steady stream of water
appears.
NOTE: Make sure the faucet is turned on fully and that
there are no kinks or leaks in the hose.
To start the engine:

Turn the fuel valve to the ON position.
 Pull choke to the start position.
 Grasp the recoil starter and pull slowly until resistance is
felt. Give the recoil starter a short, brisk pull to start the
engine.
NOTE: Do not allow the recoil starter to snap back after
starting; return it gently to its original place.
 Let engine run for several seconds, then push choke in
to the run position.
To stop the engine:

Press and hold the OFF switch until the engine stops.
 Turn the fuel valve to the OFF position.
 Pull trigger to release water pressure.
WARNING:
While operating and storing, keep at least 3 feet of
clearance on all sides of this product, including overhead.
Allow a minimum of 30 minutes of “cool down” time
before storage. Heat created by muffler and exhaust
gases may be hot enough to cause serious burns and/
or ignite combustible objects.
USING THE SPRAY WAND TRIGGER
See Figure 14.
For greater control and safety, keep both hands on the trigger
handle at all times.

Pull back and hold the trigger to operate the pressure
washer.
 Release the trigger to stop the flow of water through the
nozzle.
To engage the lock out:

Push up on the lock out until it clicks into the slot.
To disengage the lock out:

Push the lock out down and into its original position.
To use the spray wand, start with the nozzle 1-2 ft. away
from the cleaning surface. Carefully approach the surface
just until the desired level of cleaning is achieved. If the spray
is too close it can damage the cleaning surface.
OPERATION
