6.2 Preparing for operation
6 Commissioning
Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany
Telephone: +49 711 3409-0, Telefax: +49 711 3409-133, E-Mail: [email protected]
6-8
 Connection cable configuration when using:
- 2 plug-in connectors "SafetyNET p Connector RJ45"
- 1 connection cable "SafetyNET p Cable"
(available as accessory, see order reference)
yellow
white
orange
blue
yellow
white
orange
blue
yellow
white
orange
blue
yellow
white
orange
blue
SafetyNET p Connector RJ45 SafetyNET p Connector RJ45
SafetyNET p Cable
AB
C
D
AB
C
D
PIN 1
PIN 3
PIN 2
PIN 6 PIN 6
PIN 2
PIN 3
PIN 1
