Technical details
Operating Manual PSSu H m F DPsafe SN SD
1002933­EN­02 35
Electrical data 312066
Internal supply voltage (module supply)
Output voltage int. system
Voltage 5 V
Voltage tolerance ­2 %/+3 %
Potential isolation 3050 V
Current load capacity 2,0 A
Buffer in the case of supply interruptions in accord­
ance with
EN 61131­2, EN 61496­1
Short circuit­proof Yes
CPU 312066
Real­time clock for time and date, buffered
Resolution 1 s
Deviation +/­ 10s/Day
Max. number of FS tasks 1
Max. number of variables with elementary data types
on the FS resource
10.000
Min. cycle time, FS tasks 10 ms
Working memory (RAM) 64 MB
Memory for the user program per resource 2 MB
Removable data medium 312066
Type SD card
External communication 312066
Max. number of IP connections 32
Modbus/TCP
Cycle time (t_ExtCo) 2...2 000 000 ms
Raw UDP
Memory size 8 Kbyte
Cycle time (t_ExtCo) 2...2 000 000 ms
SafetyNET p interface 312066
Number 1
IP address (automatically off) 169.254.X.Y
Connection RJ45
Transmission rates 10 MBit/s, 100 MBit/s
Set via automatic
Max. number of ST­Tx and ST­Rx connections 5
Max. number of FS­Tx and FS­Rx connections 5
Cycle time (t_SNp) 10...60 000 ms
Max. number of variables with elementary ST data
types
2500
Max. number of variables with elementary FS data
types
2000
PROFIBUS DP interface 312066
Number 1
Unit type Slave
Station address 0 ... 126d
F­address 1 ... 511d
