Technical details
Operating Manual PMCprotego S2­2(­C)
1002529­EN­02 72
Environmental data 680006 680009
Storage temperature
In accordance with the standard DIN EN 60721­3­1 DIN EN 60721­3­1
Temperature range ­25 ­ 55 °C ­25 ­ 55 °C
Climatic suitability
In accordance with the standard DIN EN 60721­3­3 DIN EN 60721­3­3
Humidity 85 % r.h. 85 % r.h.
Condensation during operation Not permitted Not permitted
EMC EN 61800­3 EN 61800­3
Vibration
In accordance with the standard IEC 721­3­3 IEC 721­3­3
Airgap creepage
In accordance with the standard EN 61800­5­1 EN 61800­5­1
Overvoltage category II II
Pollution degree 2 2
Protection type
In accordance with the standard EN 60529 EN 60529
Mounting area (e.g. control cab­
inet)
IP54 IP54
Housing IP20 IP20
Terminals IP20 IP20
Mechanical data 680006 680009
Material
Front Stahl 1.4016 Stahl 1.4016
Top Polyester film Polyester film
Conductor cross section with screw
terminals
Rigid single­core, flexible multi­
core or multi­core with crimp
connector
1,0 mm² 1,0 mm²
Mounting type plug­in plug­in
Dimensions
Height 142,0 mm 142,0 mm
Width 18,5 mm 18,5 mm
Depth 103,0 mm 103,0 mm
Weight 150 g 150 g
