9
FORM NO. L-20334-C-0404
SPECIFICATIONS
Detection line width
0.2 mm [0.008 in] or greater (May differ depending on color or gradation of the line.)
Detection line width
0.2 mm [0.008 in] or greater (May differ depending on color or gradation of the line.)
Field of view
2.5 mm / 5 mm / 10 mm [0.1 in / 0.2 in / 0.4 in] diameter (selectable)
Resolution
14 µm [0.0005 in]
Light receiving element
CCD linear image sensor
Light source
High luminance LED (2 colors; blue and red)
Power supply
+15 VDC, 300 mA
-15 VDC, 50 mA
Ouput
Position signal
Detection field view: 2.5 mm (0.3 V -- 0.5 V low) (2.4 VDC -- 3.7 V high)
Detection field view: 5 mm (0.2 V -- 0.6 V low) (1.7 VDC -- 4.4 V high)
Detection field view: 10 mm (0.1 V -- 0.7 V low) (0.3 mV -- 5.8 V high)
Actuator/lock signal Open collector 30 V, 0.1 A max, ON when the target is lost from the field of view
Mass
LH100: 0.6 kg [1.3 lb] (including cable)
Mounting Bracket: 0.5 kg [1.0 lb]
Attached cable length
5 m [16 ft]
Ambient temperature
0° -- 50° C [ 32° -- 122° F]
