TOYOTA 2013 Prius PHV User Manual
Page 565
499
4-3. Do-it-yourself maintenance
PRIUS PHV_OM_OM47787U_(U)
4
Mai
n
tenan
ce and care
FUSE
Ampere
Circuit
11
IGCT
30A
PCU, IGCT NO.2, IGCT NO.3
12
DC/DC-S
5A
Inverter and converter
13
P CON MAIN
7.5A
P position control system, P posi-
tion switch
14
AM2
7.5A
Power management system
15
ECU-B2
7.5A
Smart key system, hybrid system
16
MAYDAY/DCM
10A
MAYDAY/DCM
17
PIMR
10A
Charge system
18
TURN & HAZ
10A
Turn signal lights
19
ETCS
10A
Multiport fuel injection system/
sequential multiport fuel injection
system
20
ABS MAIN
NO.1
20A
Anti-lock brake system
21
H-LP LH LO
15A
Left-hand headlight (low beam)
22
P/I 2
40A
P position control system, horn,
headlight low beams, back-up
lights
23
ABS MTR 1
30A
Anti-lock brake system
24
ABS MTR 2
30A
Anti-lock brake system
25
H-LP HI MAIN
20A
Headlight high beams, daytime
running lights
26
DRL
7.5A
Daytime running lights
27
AMP NO.2
30A
Audio system, navigation system
28
P/I 1
60A
IG2, EFI MAIN, BATT FAN
29
EPS
60A
Electric power steering
