NOTE:
For checking and replacing fuses on
QR25DE engine models, see a NISSAN
dealer.
If any electrical equipment does not come on,
check for an open fuse.
1. Be sure the ignition switch and the headlight
switch are OFF.
2. Open the engine hood.
3. Remove the fuse box cover by pushing the
tabs
᭺
A
and lifting the cover up from the
front
᭺
B
.
4. Remove the fuse with the fuse puller. The
fuse puller is located in the center of the fuse
block in the passenger compartment.
5. If the fuse is open
᭺
A
, replace it with a new
fuse
᭺
B
.
6. If a new fuse also opens, have the electrical
system checked and repaired by a NISSAN
dealer.
Fusible links
If any electrical equipment does not operate and
the fuses are in good condition, check the fusible
links in the holders
᭺
A
,
᭺
B
and
᭺
C
. If any of these
fusible links are melted, replace only with genuine
NISSAN parts.
For checking and replacing the fusible links in
holders
᭺
A
and
᭺
B
, see a NISSAN dealer.
WDI0452
Type A
LDI0546
Maintenance and do-it-yourself
8-23
