Chapter 3: System Setup
NDiS 163 User Manual
5. Insert the 2 rings (ring 1 then ring 2) into the TV antenna jack.
Ring 1
Ring 2
TV antenna jack
6. Now mount the TV antenna jack to the TV antenna hole located at the
front panel of the chassis then tighten the rings.
TV antenna jack
