California Instruments Revision H 68
User Manual MX Series CTSH Compliance Test System
Setting Description
or not by setting the Disable checkbox..
IEEE-488 control This selection requires the presence of a National
Instruments IEEE-488 controller card or compatible card in
the PC. This interface is not supplied as part of the CTS
system but may be added as an option. The Verify Source
must be used to make sure the AC Source can be found.
The AC source must be powered up. The View Bus button
may be used to bring up the command trace for trouble
shooting purposes if the presence of source cannot be
verified. When using remote control, the user can select to
have the front panel locked or not by setting the Disable
checkbox.
Test Data Test data for each test can be saved to disk for later replay or report generation. If
this option is not selected, the test cannot be replayed later or printed. For most
situations, it is recommended to save the test data. For debugging sessions, it
may be acceptable to turn off this option to preserve disk space.
Sample and Hold This option does not apply to the CTS system.
Time filter duration
for transitory
harmonics filtering. This value should be set for 1.5 seconds to comply with the IEC 61000-3-12
standard. Future standard changes may require this value to be changed.
Table 5-2: IEC Harmonics Advanced Setup Parameters
