APC-3x84A /APC-3x85AUser Manual 11
Chapter 2 Hardware
2.1 Mainboard
Specifications
Board Size 170mm x 113mm
CPU Support Intel Atom N2600 /1.60GHz
Chipset Intel NM10 Express
Memory
Support
Onboard 2GB DDRIII SDRAM
Graphics Integrated Intel GMA 3600 (N2600)
Display Mode 1 x CRT Port
1 x LVDS1 (18/24-bit single LVDS)
Support
Resolution
Up to 1920 x1200 for CRT
Up to 1366 x768 for LVDS1 (N2600)
Dual Display CRT+LVDS1
Super I/O Winbond W83627UHG-E
BIOS AMIBIOS
Storage 1 x SATA Connector (7P)
1 x SATA Connector (7P+15P)
1 x SD Socket (USB to SD)
Ethernet 2 x PCIe GbE LAN by Realtek RTL8111E
USB
2 x USB 2.0 (type A)stack ports (USB4/USB5)
2 x USB 2.0 Pin header via CN3 (USB2/USB3)
2 x USB 2.0 Pin header via CN1 (USB0/USB1)
1 x USB 2.0 for MPCIE1 (USB7)
Mini-PCIe(USB7)
Serial
1 x RS-232/RS-422/RS-485, DB9 connector for external (COM1)
pin 9 w/5V/12V/Ring select
1 x RS232 port, DB9 connector for external (COM2)
pin 9 w/5V/12V/Ring select
1 x RS422/485 header via CN2 (COM3)
2 x UART via CN3 (COM5,COM6)
