48
Practical Application d
Floral patterns – Creating a floral pattern from a shape –
Cre
at
ing Va
rio
u
s
E
m
broide
ry
De
s
ign
s
4
Select the base circle pattern
(outermost).
5
Click the [Shapes] tab.
6
Select [Motif Stitch] from the [Line
sew type] selector in the [Sew]
group.
7
Click the [Color] tab, and then click
[Kelly] in the color thread list.
8
Click the [Sewing Attributes] tab,
and then click
.
→ The dialog box appears.
9
Select the desired motif stitch
pattern from the thumbnails in the
[Browse] dialog box, and then click
[OK].
For this example, select [motif001].
10
Specify the following settings for the
motif pattern.
Motif height
4.0 mm
Motif width
5.0 mm
H-Arrange
V-Arrange
Offset
0.0 mm
Spacing
-0.5 mm
Run pitch
5.0 mm
Start/End Type
Feed
11
Specify settings for motif patterns
for the two inner circle patterns by
repeating steps
5
through
10
.
