Baby Lock Palette 10 (ECS10) Reference Guide - Manual (Page 76)

67
Practical Application g
Symbol – Specifying the sewing direction for each separate shape –
Step 3
Optimizing the sewing order
Step 4
Grouping pattern parts
1
In the [Sewing Order] pane, change
the sewing order by dragging the
frames to the desired positions.
For this example, change the order as
shown in the figure left.
2
In the [Sewing Order] pane, drag the
pointer to draw a selection frame
around all the pattern parts.
3
Click at the top of the [Sewing
Order] pane to automatically
optimize the sewing order.
b
Find the most efficient sewing order by viewing the pattern in the [Design Page] in [Stitch View] mode to
check the stitching or by previewing the stitching with the [Stitch Simulator].
1
Select , and then drag the
pointer in the [Design Page] to draw
a selection frame around the entire
pattern.
2
Click [Group] in the [Edit] group, and
then click [Group] in the menu.
By grouping multiple patterns, they can
be enlarged/reduced or rotated
together in a single operation.
a
g
b
f
c
e
d
