9437200990 Rev C 3
Communication
IDP-1200 communication with the control system cannot take place until the Ethernet communication
settings are configured for the IDP-1200 and the control system peripheral devices. The following
procedures describe how to configure the communication settings for the IDP-1200 and peripheral
devices.
IDP-1200 Ethernet Settings
Perform the following steps to configure the local Ethernet settings for the IDP-1200.
1. Press the Index button on any IDP-1200 page to access the General Index page.
2. Press the Setup button on the General Index page to access the System Configuration page.
3. Press the Offline Mode button.
4. Press the Main Unit Settings button located at the top of the page.
5. Press the Ethernet Local Settings button located at the right of page center.
6. Tap on the Local Name box and enter a local name for the main (IDP-1200) unit.
7. Enter the IP Address, Subnet Mask, Port, and Gateway as assigned by the network administrator.
8. Press the Back button located at the bottom of the page.
9. Press the Save button located at the bottom of the page.
10. Press the Yes button when prompted to save the current settings.
Control System Peripheral Settings
Perform the following steps to configure the control system peripherals for communication with the main
(IDP-1200) unit.
1. Press the Index button on any IDP-1200 page to access the General Index page.
2. Press the Setup button on the General Index page to access the System Configuration page.
3. Press the Offline Mode button.
4. Press the Peripheral Settings button located at the top of the page
5. Press the Device/PLC Settings button located at the left of page center.
6. Press the Schneider Electric Industries button in the center of the page.
7. Press the Device button located at the top of the page.
8. Enter the IP Address, Port, and Unit ID for each of the following devices as assigned by the
network administrator. Your system may not contain all of the devices listed here.
a. em (ECM Main)
b. fm (FCIM Main)
c. er (ECM Redundant)
d. fr (FCIM Redundant)
e. es (ECM Supervisory)
f. fs (FCIM Supervisory)
9. Note that em and fm share the same IP address, er and fr share the same IP address, and es
and fs share the same IP address.
IDP-1200 Communication
