BECKHOFF EtherCAT Registers Section II - Manual (Page 64)

MII Management Interface (0x0510:0x0515)
II-52 Slave Controller – Register Description
Table 72: Register PHY Address (0x0512)
ESC20 ET1100 ET1200 IP Core
[7] [7] [7]
[7]
V3.0.0/
V3.00c
Bit Description ECAT PDI Reset Value
4:0 PHY Address r/(w) r/(w) 0
6:5 Reserved, write 0 r/- r/-
7 Show configured PHY address of port 0-3 in
register 0x0510[7:3]. Select port x with bits
[4:0] of this register (valid values are 0-3):
0:
Show address of port 0 (offset)
1: Show individual address of port x
r/(w) r/(w) 0
NOTE: r/ (w): write access depends on assignment of MI (ECAT/PDI). Write access is generally blocked if
Management interface is busy (0x0510.15=1).
Table 73: Register PHY Register Address (0x0513)
ESC20 ET1100 ET1200 IP Core
Bit Description ECAT PDI Reset Value
4:0 Address of PHY Register that shall be
read/written r/(w) r/(w) 0
7:5 Reserved, write 0 r/- r/- 0
NOTE: r/ (w): write access depends on assignment of MI (ECAT/PDI). Write access is generally blocked if
Management interface is busy (0x0510.15=1).
Table 74: Register PHY Data (0x0514:0x0515)
ESC20 ET1100 ET1200 IP Core
Bit Description ECAT PDI Reset Value
15:0 PHY Read/Write Data r/(w) r/(w) 0
NOTE: r/ (w): write access depends on assignment of MI (ECAT/PDI). Access is generally blocked if Management
interface is busy (0x0510.15=1).
Table 75: Register MII Management ECAT Access State (0x0516)
ESC20 ET1100 ET1200 IP Core
V2.0.0/
V2.00a
Bit Description ECAT PDI Reset Value
0 Access to MII management:
0:
ECAT enables PDI takeover of MII
management control
1: ECAT claims exclusive access to MII
management
r/(w) r/- 0
7:1 Reserved, write 0 r/- r/- 0
NOTE: r/ (w): write access is only possible if 0x0517.0=0.
