III.16 Torque characteristics AM277S
III.17 Torque characteristics AM297K
30 Motor series AM227..297
Drawings
12/2001 - A.4.036.3/10, 11
BECKHOFF
Legend:
X-axis : Speed [min
-1
]
Y-axis : Torque [Nm]
1 : Performance curve
2 : cut-off characteristic M(n)
3 : Rated speed n
n
1
3
2
Legend:
X-axis : Speed [min
-1
]
Y-axis : Torque [Nm]
1 : Performance curve
2 : cut-off characteristic M(n)
3 : Rated speed n
n
1
3
2
