I/O configuration
FM33xx 21
Linking into the Simatic Manager
The following steps are required for linking the TC-Plug into the Simatic
Manager in simple mode and for configuring it.
• Install the GSD file in the Simatic Manager, add the module in the
hardware configuration and set the PROFIBUS address;
• Data format: MOTOROLA; Connection Channel 0: Channel
connected; set;
• n times for n channels: Add Channel compact, set the required I-
addresses for the data;
• Append Channel State Open Circuit;
• Append Channel State Back Voltage;
• Append Measure Control;
• Append Measure State;
• Download the configuration into the station;
• Start master;
• Reset TC-Plug by switching it on and off (power is removed);
