PCB-4000 1+1 Phase Combiner Revision 2
Appendix A MN/PCB4000.IOM
A–2
A.1.1 Summary of Available Assemblies
Table A‐1 outlines availability of assembly kits for the PCB‐4000. This includes common subassemblies that may be shared amongst the
available configurations. Note that the model of the SSPA pair deployed within a PCB‐4000 1+1 Phase Combined System may vary and,
as such, the illustrations provided herein may or may not intentionally omit the depiction of any installed SSPA pair.
Table A-1. Appendix Figure Quick Reference
Assembly
Type
Sect. Figure
Table
(BOM)
CEFD Part No. Description
Common
A.2.1 A-1 A-2 PL/12319-1 Universal Pole Mounting Kit
A.2.2 A-2 A-3 KT-0000017 Unistrut Mounting Kit
A.2.3 A-3 A-4 KT/12300-1 HPOD Mooting Kit
PCCB A.3 A-4 A-5
PL/11285-1 (p/o KT/11344-1) 1+1 Phase Combiner Box, X-Band
PL-0000030 (p/o KT-0000056) 1+1 Phase Combiner Box, C-Band
PL-0021051(p/o KT-0020623) 1+1 Phase Combiner Box, Ku-Band
X-Band
A.3.1.1 A-5 A-6 KT/11344-1 X-Band Top Assembly Kit
A.3.1.2 A-6 A-7 KT/11387 X-Band Waveguide and Switch Assembly Kit
C-Band
A.3.2.1 A-7 A-8 KT-0000055 C-Band Top Assembly Kit
A.3.2.2 A-8 A-9 KT-0000054 C-Band Waveguide and Switch Assembly Kit
Ku-Band
A.3.3.1 A-9 A-10 KT-0020621 Ku-Band Top Assembly Kit
A.3.3.2 A-10 A-11 KT-0020623 Ku-Band Waveguide and Switch Assembly Kit
