Scoreboard Maintenance & Troubleshooting
Refer to the following table for Daktronics scoreboard replacement parts.
Description Daktronics Part No.
LED Indicator, BALL, STRIKE, OUT, H/E 0P-1192-0292
18" LED Digit 0P-1192-0291
8 Column Driver 0P-1192-0392
16 Column Driver 0P-1192-0384
Transformer T-1066
15" LED Digit 0P-1192-0308
18" LED Ones Digit 0P-1192-0304
24" LED Horizontal Segment 0P-1192-0305
24" LED Vertical Segments 0P-1192-0306
This section lists some of the more common problems with the scoreboard and indicates
possible causes and/or corrective actions.
Symptom/Condition Possible Cause
Scoreboard will not light  Console not connected or poor connection
 No power to control console
 No power to the scoreboard
Garbled display  Internal driver logic malfunction
 Control console malfunction
Digit will not light  Black wire to digit broken
 Poor contact at driver connection.
 Driver malfunction
Segment will not light  Broken LED or connection
 Driver shift register failure
 Broken wire between driver and digit
 Poor contact at driver connector
Segment stays lit  Driver shift register failure
 Short circuit on digit
Data appears in the wrong
place on the scoreboard
 Incorrect address settings on drivers (consult
tables and set correct addresses)
