Sound System Components 3
Section 2: Sound System Components
2.1 Equipment Overview
The Sportsound 2000HD audio system consists of the following elements:
 Sound Cabinet
 Fiber Conversion Box
 Source Equipment
 Signal Cables
Note: All products in this system are tested individually for product safety approval.
2.2 Sound Cabinet
The Sportsound 2000HD audio
system cabinet (Figure 3) is 6'-0"
(1829 mm) high, 22'-0" (6706 mm)
wide, and 3'-6" (1067 mm) deep.
It is composed of a steel skeleton
sheeted in custom aluminum
paneling with eight rear access
doors. The cabinet is powder coat
black with a wrinkle finish.
Grille
The grille of the cabinet consists of a woven flame resistant acoustical mesh. The mesh can be
printed in a variety of colors to display advertising, sponsors, or logo designs. The printable
area is 5'-4
3 /
4
" (1645 mm) high by 21'-9" (6630 mm) wide.
Drivers
Three different types of drivers are used in the sound cabinet:
 12" (305 mm) low frequency drivers: Daktronics part # A-2306: (Figure 4)
 8" (203 mm) mid-range drivers: Daktronics part # A-2305 (Figure 5)
 1.4" (36 mm) high frequency drivers: Daktronics part # A-2302 (Figure 6)
Figure 3: Sportsound 2000HD Cabinet with Grille
Figure 4: A-2306
Figure 5: A-2305
Figure 6: A-2302
