Headset Operation
N OTE : 24 V power is required.
1. Connect the headset to the eight-pin headset jack on the front panel.
2. Using the 16-button keypad, dial the extension of the desired station. Optional - Press a call button
located on the front panel. The front panel LED illuminates to indicate a call in progress.
3. Speak into the headset microphone to transmit audio. If necessary, talk/listen control can be
controlled using the * button on the keypad or by using the station’s footswitch input.
4. Audio is received over the headset receiver. N
OTE : Audio will not broadcast over the handset,
external speaker, or Remote Amplifiers whenever the headset is installed.
5. Terminate the call by depressing the # button.
6. If an incoming call, page, alarm, or music arrives while the headset is connected, the audio will be
broadcast over the headset receiver but will not broadcast over the station’s speaker, the external
speaker, or the Remote Amplifiers.
Paging
This station is capable of sending and receiving all-calls and group calls. Refer to the “All-Call” and
“Group Call” sections of the central cabinet instruction manual for configuration details. Hands-free
stations will broadcast pages over the external speaker and remote amplifiers.
NOTE
Pages are not broadcast over the external speaker and Remote Amplifiers whenever the
handset is off hook or the optional headset is installed or 24 V power is not supplied.
Alarms and Music
This station is capable of receiving alarms and music. Refer to the “Alarms” and “Music” sections of the
central cabinet instruction manual for configuration details. Hands-free stations will broadcast alarms and
music over the external speaker and remote amplifiers.
NOTE
Alarms and music will not broadcast over the external speaker and remote amplifiers
whenever the handset is off-hook, the optional headset is installed, or 24 V power is not supplied.
