APPENDIX B: Model 7618 End-of-Line Flame Arrester (2"-12")
ITEM DESCRIPTION STANDARD MATERIALS OF CONSTRUCTION
ALUMINUM CARBON STL 316 SS
1 BASE AL (356 T6) CS (WCB) 316 SS (CF-8M)
2 HANDLE ALUM CS SS
3 HEX NUT SS SS SS
4 STUD SS SS SS
5 ELEMENT PLUG SS SS 303 SS
6 ELEMENT ROD SS SS 316 SS
7 ELEMENT GRID ALUM 316 SS 316 SS
8 * ELEMENT HOUSING ALUM CS 316 SS
9 COUPLING (OPTIONAL) ALUM CS 316 SS
10 PIPE PLUG (OPTIONAL) ALUM CS 316 SS
11 * GASKET NON-ASB NON-ASB NON-ASB
12 * FLAME ELEMENT ALUM (1) 316 SS 316 SS
13 EYE NUT CS CS 316 SS
14 HEX NUT SS SS SS
15 WEATHERHOOD ALUM CS 316 SS
16 BIRD SCREEN SS SS SS
17 ADAPTER PLATE CS CS 316 SS
(1) Available in 316 SS
* Recommended Spare Parts
