APPENDIX E: Model 7628 Flame Arrester (14" and Larger)
ITEM DESCRIPTION STANDARD MATERIALS OF CONSTRUCTION
ALUMINUM CARBON STL 316 SS
1 * ELEMENT HOUSING ALUM CS 316 SS
2 BASE AL (356 T6) CS (WCB) 316 SS (CF-8M)
3 * FLAME ELEMENT ALUM (1) 316 SS 316 SS
4 COUPLING (OPTIONAL) ALUM CS 316 SS
5 RETAINER ELEMENT ALUM 316 SS 316 SS
6 ELEMENT SHAFT SS 316 SS 316 SS
7 STUD SS SS SS
8 HEX NUT SS SS SS
9 * GASKET NON-ASB NON-ASB NON-ASB
10 LIFTING LUG ALUM CS 316 SS
11 PIPE PLUG (OPTIONAL) ALUM CS 316 SS
12 GUIDE ROLLER ALUM CS 316 SS
(1) Available in 316 SS
* Recommended Spare Parts
