APPENDIX C: Model 7618 Flame Arrester (14" and Larger)
ITEM DESCRIPTION STANDARD MATERIALS OF CONSTRUCTION
ALUMINUM CARBON STL 316 SS
1 BASE AL (356 T6) CS (WCB) 316 SS (CF-8M)
2 SPACER ALUM CS 316 SS
3 * FLAME ELEMENT ALUM (1) 316 SS 316 SS
4 * ELEMENT HOUSING ALUM CS 316 SS
5 STUD SS SS SS
6 HEX NUT SS SS SS
7 ELEMENT GRID ALUM 316 SS 316 SS
8 ELEMENT SHAFT SS SS 316 SS
9 * GASKET NON-ASB NON-ASB NON-ASB
10 LIFTING LUG ALUM CS 316 SS
11 PIPE PLUG (OPTIONAL) ALUM CS 316 SS
12 COUPLING (OPTIONAL) ALUM CS 316 SS
13 SPREADER HEX NUT SS SS SS
(1) Available in 316 SS
* Recommended Spare Parts
