Page 43: Chipset
BIOS SETUP
MI987 User’s Manual
39
System Agent (SA) Configuration
Aptio Setup Utility – Copyright © 2012 American Megatrends, Inc.
Main Advanced
Chipset
Boot
Security
Save & Exit
System Agent Bridge Name Haswell
→ ← Select Screen
↑↓ Select Item
Enter: Select
+- Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
System Agent RC Version
1.6.2.0
VT-d Capability
Supported
VT-d
Enabled
► Graphics Configuration
VT-d
Check to enable VT-d function on MCH.
Graphics Configuration
Aptio Setup Utility – Copyright © 2012 American Megatrends, Inc.
Main Advanced
Chipset
Boot
Security
Save & Exit
Graphics Configuration
→ ← Select Screen
↑↓ Select Item
Enter: Select
+- Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
IGFX VBIOS Version
2170
IGfx Frequency
700 MHz
Primary Display
Primary PEG
Primary PCIE
Auto
Auto
Auto
Internal Graphics
Auto
Aperture Size
256MB
DVMT Pre-Allocated
32M
DVMT Total Gfx Mem
Gfx Low Power Mode
256MB
Enabled
Primary Display
Select which of IGFX/PEG/PCI graphics device should be Primary
Display or select SG for switchable Gfx.
Primary PEG
Select PEG0/PEG1/PEG2/PEG3 Graphics device should be Primary
PEG.
