CABINET INSTALLATION INSTRUCTIONS
6.3
Providing a Suitable Flue
Ventilation is provided by thermostatically controlled ventilation fans which expel oven vented air through slots
below the control panel.
6.4
Required Clearances
(Required Clearances Around Domestic Cooking Appliances - Extract from AG601)
All cooktops, rangehoods and/or exhaust fans shall be installed in accordance with the manufacturer’s
instructions. However, in no case shall the clearance between the top of the highest burner on the cooktop
to the lowest extruding part of the rangehood or exhaust fan (A) be less than 600 mm. (Clause 5.6.1.5)
Any other combustible materials less than 600 mm above the top of the highest burner shall be protected
for the full width and depth of the cooking surface in accordance with Clause 5.6.1.2. However, in no case
shall this clearance be less that 450 mm.
If (B) is less than 200 mm (275 mm for wok burner), any surrounding vertical combustible material shall be
protected in accordance with Clause 5.6.1.4 to a height (C) of not less than 150 mm above the burners for
the full dimension (length or width) of the cooktop.
Protection of the rear wall is required if the appliance is fitted without a splashback.
If (D), the distance to a horizontal combustible material from the periphery of the nearest burner is less
than 200 mm (275 mm for Wok burners), then (E) shall not be less than 13 mm (Clause 5.6.1.3). The dimension
(E) is measured from the hob down to the horizontal surface.
