La Crosse Technology WS-1910 User Manual
Page 7
25
6.
MAX outdoor humidity with the date and time of recording
7.
MIN Wind chill temperature with the date and time of recording
8.
MAX Wind chill temperature with the date and time of recording
9.
MIN Relative pressure with the date and time of recording
MIN icon
MIN wind chill
value
Time and date
or recording
MIN icon
MIN outdoor
humidity value
Time and date
or recording
26
10. MAX Relative pressure with the date and time of recording
11. MAX wind speed with the date and time of recording
MAX icon
MAX relative
pressure value
Time and date
or recording
MAX icon
MAX wind
speed value
Time and date
or recording
27
12. MAX Gust with the date and time of recording
13. MAX 24 hour rainfall (optional) with the date and time of recording
RESET THE MAXIMUM AND MINIMUM WEATHER DATA
To reset the aforementioned maximum or minimum weather data 1. to 13., you shall need
to reset each of the data independently.
MAX icon
MAX Gust value
Time and date
or recording
24 hour
rainfall icon
24h rainfall
amount
The 24h rainfall value
is counted from this
time and date
28
1.
Press MIN/MAX key to show the desired weather data. For instance, if you want to
reset the minimum humidity, in the normal display you shall press the MIN/MAX key
three times to show the min humidity value.
2.
Press and hold the SET key for about 2 seconds, then the "RESET" icon will appear
at the bottom part of the LCD.
3.
Press the + key once, then the stored value will be reset to the current value and
current time.
4.
Press the HISTORY key to return to normal display mode.
10. Total rainfall amount (optional) with the date and time of recording
The total rainfall measurement is displayed in the last section of the LCD, in the unit of mm
or inch. It shows the total rainfall accumulated since last reset of the weather station.
In normal display mode, press the MIN/MAX key fourteen times to show the total rainfall
value. The "RESET" icon will also be shown at the same time.
To reset the rainfall reading, press the + key once when the Rainfall value and "Reset"
icon is shown. Then the total rainfall amount will be reset to 0, and the time updated to
current time.
Note:
After power up, the time and date and total rainfall are displayed as "- - -". After time is
adjusted manually, the set time will be shown.
Total rainfall icon
Total rainfall
amount
The total rainfall value is
counted from this time and
date
