English -
10
4.2.1.2 Installation steps
1. Please adjust DIP switch at first prior to installation.
<Remark> Please refer to
Chapter 7 DIP Switch Setting
for the
relevant descriptions on DIP Switch.
2. Place the camera on a flat desk directly to ensure the normal
vertical and horizontal operation of the machine.
4.2.2
I would like to install VC200 on the ceiling
4.2.2.1 Prepare for the parts and equipment required during the
installation
1. Accessories of VC200 in the box (metal plates A, B, M3 screw x 7)
2. Screw for locking on ceiling mounted hanger x 4
3. Drilling machine, screw driver, ladder
4.2.2.2 Diagram of Size
1. Metal plate B - Ceiling side
Metal plate B
Locking screw
Metal plate B
Locking eyebolt
