English -

13

4.2.2.3 Precautions for installation

1. Before installation, please confirm the orientation of the

machine relative to the object to be captured

2. It is recommended that the machine should be set at a distance

of more than 1 meter away from the object to be captured.

Please adjust for a best distance according to the magnification

of the lens

3. The machine (including metal plates) is weighed at about 2.5 kg.

If it is to be installed on the ceiling, please use the hanger that

has obtained UL security approval to prevent the machine from

falling down.

4. Please check whether the camera is installed stably on a

periodical basis

4.2.2.4 Installation steps

1. Please adjust resolution on DIP Switch at first

<Remark> Please refer to

Chapter 7 DIP Switch Setting

for the

relevant descriptions on DIP Switch.

1 meter ↑
