English - 24
Manual R
Gain
0~255
Manually adjust the red
gain
This item can be turned
on when the mode is
selected to Manual
Manual B
Gain
0~255
Manually adjust the blue
gain
This item can be turned
on when the mode is
selected to Manual
Aperture 1~A~16 Adjust the aperture
Picture effect
1. Off
2. Neg
3. B&W
Set the picture effect
Image Mode
Mode1
Mode2
Mode3
Saturation
0~2~14
Hue
0~8~14
Gamma 0~4
Pan Tilt
Zoom
Pan/Tilt Limit ON/Off
Turn on/off the angle limit
setting
Pan Right
Limit
0~170 Limit the right angle
Pan Left Limit -170~0 Limit the left angle
Tilt UP Limit 0~90 Limit the upward angle
Tilt Down
Limit
-30~0 Limit the downward angle
D-Zoom Limit x1~x12
Preset Speed
1. 150 deg/sec
2. 250 deg/sec
3. 300 deg/sec
System C-Video NTSC/PAL Video Mode
