Maytag MSB26C6MDM - Manual (Page 19)

19
Refrigerator Compartment - Lower Lights
Light Shield Removal:
■
Slide the light shield to the right to remove the left end from
the wall slots, then pull the right end out of its wall slots.
Replacement Bulb:
■
If the burned-out light is a full-size LED bulb, replace it with
Whirlpool part number W10565137A (a 3.6 watt LED bulb).
■
If the burned-out light is an incandescent bulb, replace it with
an incandescent appliance bulb of the same size, shape and
wattage (40-watt maximum).
Light Shield Reinstallation:
■
Place the right end of the light shield into the wall slots, then
snap the left end into its wall slots.
Freezer Compartment - Upper Light
Light Shield Removal:
■
Gently squeeze the front and the bottom-rear edge of the
light shield to release the tabs from the wall slots, then pull
the light shield forward.
Replacement Bulb:
■
If the burned-out light is a full-size LED bulb, replace it with
Whirlpool part number W10565137A (a 3.6 watt LED bulb).
■
If the burned-out light is an incandescent bulb, replace it with
an incandescent appliance bulb of the same size, shape and
wattage (40-watt maximum).
Light Shield Reinstallation:
■
Align the light shield in its proper position, and snap the tabs
into the wall slots.
Freezer Compartment - Lower Light
Light Shield Removal:
■
Slide the light shield to the left to remove the right end from
the wall slots, then pull the left end out of its wall slots.
Replacement Bulb:
■
If the burned-out light is a full-size LED bulb, replace it with
Whirlpool part number W10565137A (a 3.6 watt LED bulb).
■
If the burned-out light is an incandescent bulb, replace it with
an incandescent appliance bulb of the same size, shape and
wattage (40-watt maximum).
Light Shield Reinstallation:
■
Place the left end of the light shield into the wall slots, then
snap the right end into its wall slots.
