PCI-CTR05 User's Guide Installing the PCI-CTR05
10
Pinout – main I/O connector
The board connector is a male, 37-pin D-type connector ( J1 ). Digital input, digital output, interrupt, and signals
from the 9513 are all accessible on this connector.
CTR1GATE
CTR1CLK
CTR1OUT
CTR2OUT
CTR3OUT
CTR4OUT
CTR5OUT
OSC OUT
DIN0
DIN1
DIN2
DIN3
DIN4
DIN5
DIN6
DIN7
DIN STROBE
PC +5V
J1
CTR2CLK
CTR2GATE
CTR3CLK
CTR3GATE
CTR4CLK
CTR4GATE
CTR5CLK
CTR5GATE
GND
D 0 OUT
D 1 OUT
D 2 OUT
D 3 OUT
D 4 OUT
DOUT7
DOUT6
DOUT5
IRQ INPUT
IRQ ENABLE
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
Figure 2. Board connector J1
Information on signal connections
For general information regarding digital I/O techniques, including signal conditioning and low pass filters,
refer to the Guide to Signal Connections. This document is available on our web site at
www.mccdaq.com/pdfs/signals.pdf ).
