PCI-CTR05 User's Guide

Specifications

16

J1 pin out

Table 8. Main connector J1 pin out

Pin

Signal Name

1

IRQ INPUT

2

IRQ ENABLE

3

DOUT7

4

DOUT6

5

DOUT5

6

DOUT4

7

DOUT3

8

DOUT2

9

DOUT1

10

DOUT0

11

GND

12

CTR5GATE

13

CTR5CLK

14

CTR4GATE

15

CTR4CLK

16

CTR3GATE

17

CTR3CLK

18

CTR2GATE

19

CTR2CLK

20

PC +5V

21

DIN STROBE

22

DIN7

23

DIN6

24

DIN5

25

DIN4

26

DIN3

27

DIN2

28

DIN1

29

DIN0

30

OSC OUT

31

CTR5OUT

32

CTR4OUT

33

CTR3OUT

34

CTR2OUT

35

CTR1OUT

36

CTR1CLK

37

CTR1GATE
